matrixdb视频教程 - 04matrixdb通过pxf读写hive

作者

shidb

日期

2021-05-11

Matrixdb 通过数据联邦pxf访问hive

环境介绍

sdw5 namenode hive
sdw3 matrixdb集群

hive建表及加载数据

数据样例

vim mppinfo.csv

1,matrixdb,北京
2,teradata,米国
3,hana,米国

创建表

DROP TABLE IF EXISTS mpp_info;
CREATE TABLE IF NOT EXISTS mpp_info(
id int,
name string,
area string
)
COMMENT 'mpp details'
ROW FORMAT DELIMITED FIELDS TERMINATED BY ','
LINES TERMINATED BY '\n' STORED AS TEXTFILE;

数据加载

load data local inpath '/data/dataload/mppinfo.csv' into table mpp_info;hive> load data local inpath '/data/dataload/mppinfo.csv' into table mpp_info;
Loading data to table default.mpp_info
OK
Time taken: 2.542 seconds

hive数据查看

hive> select * from mpp_info;
OK
1       matrixdb        北京
2       teradata        米国
3       hana    米国
Time taken: 0.318 seconds, Fetched: 3 row(s)

matrixdb pxf配置

配置pxf

将hdfs下的core-site.xml、hdfs-site.xml拷贝到

[root@sdw5 ~]# cp /etc/hadoop/conf.cloudera.hdfs/core-site.xml .
[root@sdw5 ~]# cp /etc/hadoop/conf.cloudera.hdfs/hdfs-site.xml .拷贝到所有matrixdb pxf节点的如下路径
cp core-site.xml /usr/local/pxf-matrixdb3/conf/servers/single_hdfs/
cp hdfs-site.xml /usr/local/pxf-matrixdb3/conf/servers/single_hdfs/

配置pxf

如果之前已经配置过，需要重置

停止pxf

[shidb@sdw3 ~]$ pxf cluster stop
Stopping PXF on 1 segment host…
PXF stopped successfully on 1 out of 1 host

重置pxf配置

[shidb@sdw3 ~]$ pxf cluster reset
Ensure your PXF cluster is stopped before continuing. This is a destructive action. Press y to continue:
y
Resetting PXF on master host and 0 segment hosts...
PXF has been reset on 1 out of 1 host

初始化pxf

[shidb@sdw3 ~]$ pxf cluster init
Initializing PXF on master host and 0 segment hosts...
PXF initialized successfully on 1 out of 1 host

pxf同步

[shidb@sdw3 ~]$ pxf cluster sync
Syncing PXF configuration files from master host to 1 segment host...
PXF configs synced successfully on 1 out of 1 host

启动PXF

[shidb@sdw3 ~]$ pxf cluster start
Starting PXF on 1 segment host...
PXF started successfully on 1 out of 1 host

查看pxf状态

[shidb@sdw3 ~]$ pxf cluster status
Checking status of PXF servers on 1 segment host...
PXF is running on 1 out of 1 host

master上单独也需要启动

[shidb@sdw3 ~]$ pxf start
Using CATALINA_BASE:   /usr/local/pxf-matrixdb3/pxf-service
Using CATALINA_HOME:   /usr/local/pxf-matrixdb3/pxf-service
Using CATALINA_TMPDIR: /usr/local/pxf-matrixdb3/pxf-service/temp
Using JRE_HOME:        /usr/local/jdk1805/jre
Using CLASSPATH:       /usr/local/pxf-matrixdb3/pxf-service/bin/bootstrap.jar:/usr/local/pxf-matrixdb3/pxf-service/bin/tomcat-juli.jar
Using CATALINA_PID:    /usr/local/pxf-matrixdb3/run/catalina.pid
Existing PID file found during start.
Tomcat appears to still be running with PID 763115. Start aborted.
If the following process is not a Tomcat process, remove the PID file and try again:
UID         PID   PPID  C STIME TTY          TIME CMD
shidb    763115      1 99 12:27 pts/178  00:00:28 /usr/local/jdk1805/jre/bin/java -Djava.util.logging.config.file=/usr/local/pxf-matrixdb3/pxf-service/conf/logging.properties -Djava.util.logg
[shidb@sdw3 ~]$

matrixdb配置

创建FDW Server

CREATE SERVER hdfs_svr FOREIGN DATA WRAPPER hdfs_pxf_fdw OPTIONS ( config ‘single_hdfs’ );

创建用户名admin的FDW User mapping

CREATE USER MAPPING FOR shidb SERVER hdfs_svr;
CREATE USER MAPPING FOR hive SERVER hdfs_svr;

matrixdb中执行创建外部表语法

DROP FOREIGN TABLE mpp_info;
CREATE FOREIGN TABLE mpp_info(
id int,
name text,
area text
)
SERVER hdfs_svr OPTIONS ( resource '/user/hive/warehouse/mpp_info', format 'text',delimiter ',');

查询

postgres=# select * from mpp_info;id |   name   | area
----+----------+------1 | matrixdb | 北京2 | teradata | 米国3 | hana     | 米国
(3 rows)

插入数据

postgres=# insert into mpp_info select * from mpp_info;
INSERT 0 3
postgres=# select * from mpp_info;id |   name   | area
----+----------+------1 | matrixdb | 北京2 | teradata | 米国3 | hana     | 米国1 | matrixdb | 北京2 | teradata | 米国3 | hana     | 米国
(6 rows)
