JOS中  "spinlock" 的实现

1. In software engineering, a spinlock is a lock which causes a thread trying to acquire it to simply wait in a loop ("spin") while repeatedly checking if the lock is available. Since the thread remains active but is not performing a useful task,the use of such a lock is a kind of busy waiting.

XCHG instruction Swaps data between two registers or a register and memory location.

LOCK汇编指令用于封锁总线.

static inline uint32_t
xchg(volatile uint32_t *addr, uint32_t newval)
{uint32_t result;// The + in "+m" denotes a read-modify-write operand.asm volatile("lock; xchgl %0, %1" :"+m" (*addr), "=a" (result) :"1" (newval) :"cc");return result;
}

每次都会返回addr指向地址处原来的值．

于是乎，在JOS中，spinlock的实现如下：

./kern/spinlock.h 这里利用结构体struct spinlock来抽象封装spinlock．

实质上，spinlock是个全局变量．这里具体的就是./kern/spinlock.h　中的全局变量结构体

extern struct spinlock kernel_lock.

// Mutual exclusion lock.
struct spinlock {unsigned locked;       // Is the lock held?
};void __spin_initlock(struct spinlock *lk, char *name);
void spin_lock(struct spinlock *lk);
void spin_unlock(struct spinlock *lk);#define spin_initlock(lock)   __spin_initlock(lock, #lock)extern struct spinlock kernel_lock;static inline void
lock_kernel(void)
{spin_lock(&kernel_lock);
}static inline void
unlock_kernel(void)
{spin_unlock(&kernel_lock);// Normally we wouldn't need to do this, but QEMU only runs// one CPU at a time and has a long time-slice.  Without the// pause, this CPU is likely to reacquire the lock before// another CPU has even been given a chance to acquire it.asm volatile("pause");
}

// Mutual exclusion spin locks.// The big kernel lock
struct spinlock kernel_lock = {
#ifdef DEBUG_SPINLOCK　.name = "kernel_lock"
#endif
};
spinlock锁的初始化
void
__spin_initlock(struct spinlock *lk, char *name)
{lk->locked = 0;
}// Acquire the lock.
// Loops (spins) until the lock is acquired.
// Holding a lock for a long time may cause
// other CPUs to waste time spinning to acquire it.
void
spin_lock(struct spinlock *lk)
{// The xchg is atomic.// It also serializes, so that reads after acquire are not// reordered before it. while (xchg(&lk->locked, 1) != 0)asm volatile ("pause");}// Release the lock.
void
spin_unlock(struct spinlock *lk)
{// The xchg serializes, so that reads before release are // not reordered after it.  The 1996 PentiumPro manual (Volume 3,// 7.2) says reads can be carried out speculatively and in// any order, which implies we need to serialize here.// But the 2007 Intel 64 Architecture Memory Ordering White// Paper says that Intel 64 and IA-32 will not move a load// after a store. So lock->locked = 0 would work here.// The xchg being asm volatile ensures gcc emits it after// the above assignments (and after the critical section).xchg(&lk->locked, 0);
}

原理还是很简单的，只是基于汇编层次的全局变量的busy waiting．
